1007D Altimeter Operators Manual 974-72007001/1.0
Options Page 33
Kongsberg Mesotech Ltd.
Port Coquitlam, BC - Canada
5.3 Auxiliary Serial Output
An optional second serial interface is available for 1007D
altimeters configured with digital telemetry, to provide an
additional output of altimeter data. This option provides a
low-latency altitude digital data output for vehicle control
from a 1007D altimeter operating in MS1000 mode.
The interface type (RS232 or RS485) and settings are
normally configured at the factory to RS232, and 9600, 8
bits/character, no parity, 1 start bit, 1 stop bit. The data
format is identical to the factory-configured default 809
format while operating in 807, 808, or MS1000 modes. In 809
mode, the current 809 format will be used. Consult the factory
if a different interface type, default baud rate, or format is
required.
This option also requires that a special connector be installed
that provides extra connections for this interface.
5.4 Analog Output
An optional 807-type analog output is also available for
0…10V range data output to a DC voltmeter or a data
acquisition system, and is active in all operating modes (807,
808, 809, MS1000). This output requires two connector pins
that can either replace the two telemetry signals (for a 4-pin
connector), or special ordered along with the digital telemetry
as part of a special connector requirement (minimum 6 pins).
