974-72007001/1.0 1007D Altimeter Operators Manual
Page 34 Options
Kongsberg Mesotech Ltd.
Port Coquitlam, BC - Canada
The default over-range output is 10.24V. Special analog
output scaling and over-range voltage specifications can be
factory ordered. On power-up or reset the output voltage is
initially zero volts.
The analog output scaling (in volts/meter) is linear with 0V
corresponding to zero range and 10V full scale analog output
corresponding to the altimeter’s maximum range setting,
which can be fixed or adjustable depending on the altimeter’s
operating mode:
807, 808 mode: maximum range is fixed to pre-programmed default
809 mode: maximum range is programmable
MS1000 mode: maximum range depends on display scale selected -
full scale output voltage corresponds to the selected
range scale.
The analog output of the altimeter is capable of supplying up
to 10 mA at 10 volts. For maximum accuracy, the load on the
output should be kept as low as possible. This is especially
important when the altimeter is operated on a long cable.
5.5 Altimeter reconfiguration utility
ALTCONFIG is an optional Windows PC application for re-
configuring numerous default settings in the Model 1007D
Altimeter, such as:
operating mode (807, 809, MS1000)
digital telemetry interface type (RS232, RS485)
analog output scaling (if available)
