ENGLISH
Introduction:
This splitter distributes the input of the HDMI signal in to eight identical outputs simultaneously. It
supports HDCP and the real HDMI 1.3b. Its video amplier bandwidth can be up to 2.25 Gpbs/225MHz.
Features:
This HDMI splitter has many features that enable it to perform in a superior manner. Among those
features you will nd:
• Easy to use: Install in seconds, no need of setting.
• Support HDMI 1.3b.
• Support highest video resolution 1080p.
• Support 225MHz/2.25Gbps per channel bandwidth.
• Support 12bit per channel deep colour.
• Support HDCP.
• Support uncompressed audio such as LPCM
• Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby True HD)
Specications:
Signal inputs/output
Input DDC signal 5 volts p-p (TTL)
Maximum single link range 1920X1080p
Output video HDMI 1.3b+ HDCP1.0/1.1
Operating frequency
Vertical frequency range 50/60Hz
Video amplier bandwidth 2.25Gbps/225MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Warranty
Limited warranty 2 Year parts and labor
Environmental
Operating temperature 0°C to +70°C
Operating humidity 10% to 85 % RH (no condensation)
Storage temperature -10°C to +80°C
Storage humidity 5% to 90 % RH (no condensation)
Power requirement
External power supply 5V DC@ 4A
Power consumption (Max) 20W
Regulatory approvals
Converter unit FCC,CE,UL
Power supply UL,CE,FCC
Accessories adapter
AC power adapter Europe standard
User manual
Note: Specications are subject to change without notice.
