KORG KP3 PARTS LIST
Part Number
Category
Part Name
QTY
510306510001
POWER MOS FET
CPH6316-TL-E (S)
1
510310510502
DOUBLE DIODES
MC2840-T112-1 (S)
1
510310511507
DIODE
RLS-73 TE-11 (S)
22
510310511506
SCHOTTKY DIODE
RB051L-40TE25 (S)
2
510310511001
ZENER DIODE
RD10M-T1B-A (B3) (S)
1
510300510503
TRANSISTOR
2SA812-T1B-A M5-7 M6 RANK(S)
3
510300510502
TRANSISTOR
2SC1623A-T1B AT
1
510300511504
TRANSISTOR
2SC3661-TB-E (S)
4
510300511009
DIGITAL TR
DTC114EKA T146 (TS) (S)
16
510300511015
DIGITAL TR
DTB143EK T146 (S)
16
510312513001
Chip LED
TO-2013BC-MRE (S)
80
510312513009
Chip LED
TO-3227BC-MRMG EE (S)
6
510316521502
SEGMENT LED
TOF-3461BH-B9
1
510646502093
X-5500 LED SPACER E10236-2(D)
1
510324021160
OPAMP
NE5532DR (TS)
3
510320511008
OPAMP
NJM4556AM-TE1-#ZZZB (S)
1
510320515502
Logic IC
SN74LVU04APWR
1
510320516029
Logic IC
SN74LV125APWR (S)
1
510320516013
Logic IC
SN74LV126APWR (S)
1
510320516016
Logic IC
IC SN74LV138ANSR (TS) (S)
2
510320516056
Logic IC
SN74LV574ANSR (S)
2
510320516010
Logic IC
SN74LV05APWR (S)
1
500324023008
IC
S-8520F33MC-BNST2G
1
510320511009
REGULATOR IC
NJM78L05UA-TE2 (TS)(S)
1
510320514025
REGULATOR IC
BA17810FP
1
510320514026
LDO IC
BD00KA5WF
1
500330003700
PHOTO COUPLER
PS9117-F3-A
1
510320512002
RESET IC
M51953BFP#CF1J (S)
1
500324018018
EEPROM
AK93C10AF-E1
1
500320004718
CPU
HD64F2215UTE16V (X5500)
1
510320516070
DSP
TMS320VC5501PGF300
1
500324026004
SDRAM
MT48LC8M16A2P-75:G TR
1
510324019513
A/D Converter
AK5381VT
1
510324038010
D/A Converter
AK4384ET-E2
1
510335520001
CRYSTAL
HC-49US 16MHZ (D)
1
510335520007
CRYSTAL
HC-49US 20.000MHZ (D)
1
510335552008
CRYSTAL
HC-49US 24.576MHZ SS (D)
1
510374524026
SLIDE VR
RA4522F-20-15C1-B5K-0015
1
510370521001
ROTARY ENCODER
RE111F-41B1-15F-15P-05
1
510374524027
ROTARY VR
RV112BCF-40-20A-B10K
1
510374524017
ROTARY VR
RV09ACF-40-20F-B5K-0057
1
510360521510
VR
R0923NOAH1B104FE0061 (D)
1
510360521511
VR
R0925GOAH1B103FE0061 (D)
1
510450520019
DIN JACK
ST-1550-01-S1-60
2
510474520501
USB CONNECTOR
GE813A02 (USB B TYPE) (D)
1
510450520008
PHONE JACK
MJ-081 (PHONE-J MONO GOLD) (D)
1
510450520009
PHONE JACK
MJ-084 (PHONE-J ST GOLD) (D)
1
510450520010
RCA PIN JACK
RCA-204G-04 (D)
2
510450522504
DC JACK
PJCP042100-42-0 (D)
1
510374522002
SLIDE SW
SK-22D06G8 2P2T (D)
1
510374522018
TOGGLE SW
TS-22E01-AC18-NI
1
510374520004
PUSH SW
SPUN192600 (D)
1
510450520011
RCA PIN JACK
SHIELD PLATE RCA-204-E (D)
2
510470521003
HARNESS
HNS-3153 FLATCABLE 5P 2MM (D)
3
510470521005
HARNESS
HNS-3155 6P 2MM BD-IN/HSG (D)
1
510474523003
CONNECTOR
5597-04APB7F (39532044)
1
500474043700
FFC CONNECTOR
XF2M-5015-1A
2
510470521552
FFC
HNS-3647
1
510474510501
CARD CONNECTOR
AXA273021T
1
500415004302
TOUCH PANEL
N010-0517-T902
1
510C33682734
PCB ASS'Y
KLM-2734-KP3 (ASS'Y)
(1)
510C33682735
PCB ASS'Y
KLM-2735/6-KP3 (ASS'Y)
(1)
510640507004
Mechanical Part
X-5500 UPPER CASE KOC-C10259
1
510640506510
Mechanical Part
X-5500 BOTTOM PLATE KOC-C30714
1
510500502531 Mechanical Part X-5500 RUBBER KEY 1 KOC-E30429 1
510500502532 Mechanical Part X-5500 RUBBER KEY 2 KOC-E30430 1
510500502533 Mechanical Part X-5500 RUBBER KEY 3 KOC-E30431 1
510500502534
Mechanical Part
X-5500 RUBBER KEY 4 KOC-E30432
1
510500502535
Mechanical Part
X-5500 ENCORDER KNOB E30426
1
510646502094
Mechanical Part
X-5500 VR KNOB KOC-E30427
2
510646502095
Mechanical Part
X-5500 SLIDER KNOB KOC-E30428
1

Korg Kp3 Specifications

General

Sampling Frequency	48 kHz
AD/DA Conversion	24-bit linear
MIDI	In, Out
Type	Effects Processor
Inputs	Mic Input (1/4" phone jack)
Outputs	Line Output (RCA pin jacks), Headphone Output (1/4" stereo phone jack)
Power Supply	DC9V (AC adapter)
Dimensions	210 (W) x 226 (D) x 49 (H) mm
Effects	Filter, Delay, Modulation
USB	Type B
External Storage	No
Sampling Time	Maximum 99.9 seconds (Total)
