Appendices
108
Options
Media
Load, Save, Utility
Data Filer functionality (Save and Load MIDI System Exclusive Data)
Controllers
Joystick, SW1, 2
Chord trigger switches
Chord trigger switches 1–4 (not velocity sensitive)
CHORD ASSIGN switch
Control Surface
CONTROL ASSIGN Switches REALTIME CONTROL, EXTERNAL, ARP
RESET CONTROLS Switch
4 knobs
REALTIME CONTROL: Realtime modulation
EXTERNAL: External mode. External MIDI control.
Arpeggio control
* In External mode, the four knobs, four chord trigger switches can be used as MIDI
controllers. 128 setups can be stored. (102 are preloaded. These allow you to control
software synthesizers or DAW software.)
Drum Track Switches = ON/OFF
Arpeggiator Switches = ON/OFF
User Interface
Display
TouchView grey-scale graphical user interface
Color 320 x 240 pixel display
MODE Switches = COMBI, PROG SEQ, GLOBAL, MEDIA
Value Controllers
Switches = q/u, 10-key numeric keypad, -, (.), ENTER, COMPARE, VALUE Slider, VALUE
Dial
BANK Switches = A…GM (used for Combination A, B, C, D)
SEQUENCER Switches = PAUSE, REW, FF, LOCATE, REC/WRITE, START/STOP
TEMPO Switches = TAP TEMPO, TEMPO Knob
Other Switches = PAGE SELECT, EXIT, VOLUME Slider, display contrast
Audio Outputs Analog
AUDIO OUTPUT
L/MONO, R
1/4" TS (Mono), unbalanced, Volume slider controls only L/Mono and R
Output Impedance 1.1kΩ stereo; 550Ω mono (L/Mono only)
Maximum Level +16.0 dBu
Load Impedance 10 kΩ or greater
Headphone output
1/4" TRS (Stereo), Volume slider
Output Impedance 33Ω
Maximum Level 32+ 32 mW @33Ω
Control Inputs
DAMPER (Supports piano-style half-damper pedals as well as standard foot switches)
ASSIGNABLE SWITCH, ASSIGNABLE PEDAL
MIDI IN, OUT
USB 1 USB (TYPE B), MIDI interface
SD-Card slot Capacity recognized: FAT32: 2 Gigabytes (GB). SDHC memory cards are not supported.
PowerAC adapter power supply connector (DC 12V 3500mA ), POWER On/Off switch
Dimensions
(W × D × H)
M50-61 1,027 × 297 × 104 (mm)/40.43" × 11.69" × 4.09"
M50-88 1,409 × 328 ×151 (mm)/55.47" × 12.91" × 5.94"
Weight
M50-61 6.8 kg/14.99 lbs.
M50-88 20.8 kg /45.86 lbs.
Power Consumption
M50-61
35W
M50-88
Accessories
AC adapter, Owner’s Manuals
CD-ROM (M50 Parameter Guide (PDF), Installation Guide (PDF), External Setups PDF, KORG USB-MIDI driver, M50
Editor/Plug-In Editor etc.)
XVP-10 Expression/Volume Pedal
EXP-2 Foot Controller
DS-1H Damper Pedal
PS-1 Pedal Switch
