SCREW
ＰＬＡＸ Ｂ ＺＭＣ ２×５
2
Ready-Made TAPE
DRAWN CHECKED APPROVED
MODEL Ｘ−２１００／２１６０
A26
TAPE W=26mm
TAMURA
TITLE
LCD UNIT 1
A5 TAPE W= 5mm
KORG INC.
NO.
3
A26
500540026600
SHILED FORM
65TS15-1.5 L=30mm
ALUMINUMTAPE
(NOTAPART)
●
●
200046362417
KLM-2425
500545050910
FFC HNS-
3460
500313006200
TOUCHPANELＬＣＤMSA2021
A5
A5
5mm
5mm
500550022700
LCD CABLE COVER
1 KOC-F41209
500545050940
FFC HNS-
3463
500475003420
HARNESS
HNS-3420
200046362417
KLM-2425
A5
200046362421
KLM-2492
A26
A26
A26
A5
A5
A5
A5
A26
A5
●
500550022800
LCD CABLE COVER
2 KOC-F41210
67.3mm
74.7mm
