Korg PA1X Service Manual

Pa1X specifications
Korg reserves the right to change the specifications without notice
USER INTERFACE
Display
240 x 320 Graphical Color Touch Screen Display
Controls
Joystick - Dial - Up/+, Down/-
Programmable Controls
4 Switches - 8 Sliders
Cursors
Master Volume - Acc/Seq Volume
Switches
Transp.-Memory-Bass Inv.-Man.Bass-Fade-Tap-Synchro-Ensemble
Help System
Hypertext - Contextual
CONNECTIONS
MIDI
IN1 - OUT1 - IN2 - OUT2 (OUT 1/2 programmable as Thru)
USB
USB connector: Type B - Format: based on USB 1.1, for connecting to
computer
Outputs
4 Analog (Left/Right/Out1/Out2) - S/PDIF coaxial Digital Output
Inputs
2 Line input-one switchable to Mic Balanced input (w/separate gain)
Headphone
1 (Front 6.3mm jack connection)
Pedals
1 Damper - 1 Assignable Footswitch/Pedal - EC 5
Power Supply
AC - Universal Voltage
OPTIONS
Hard Disk
ATA-IDE Interface – 2,5" (user installable)
Voice Processor
SUG TC1 - TC Helicon "Pitch Correction / Voice Modeling" Upgrade
CD Audio Player
Korg CDRW-1 - CD Audio and CD ROM (rewritable starting from O.S. v. 2.0)
(user installable)
CD Installation Kit
Korg CDRW1-IK Installation Kit for Korg CDRW-1
MP3 Board
EXBP-MP3 Player/Recorder board (user installable)
Video Interface
VIF3 NTSC/PAL board (user installable)
PCM RAM memory
72-pin SIMM (11-bit addressing) - supports one 16 MB part for a total of 32 MB
RAM (user installable).
PCM ROM Expansion Board
2 slots available for Korg proprietary Expansion (user installable)
Expression/Volume Pedal
Korg EXP-2 - Korg XVP-10
Multi-Switch Pedal
Korg EC5
Damper Pedal
Korg DS-1H (supports half-pedaling)
Switch Pedal
Korg PS-1

Korg PA1X Specifications

General

Polyphony	62 voices
Sound Engine	HI synthesis (Hyper Integrated)
Display	TouchView graphical touch screen
Sequencer	16-track sequencer
Storage	floppy disk drive
Connectivity	MIDI In/Out/Thru, USB
Outputs	Headphones
Inputs	Microphone Input
