MIDI 23
Standard MIDI settings
When turning the instrument on, the MIDI parameters of the SP-200 are pro-
grammed as follows:
Selecting the transmission channel
The standard MIDI has 16 separate channels available for transmission and recep-
tion of data. SP-200 always receives on all 16 channels, and transmits on a single
channel. To transmit data from the SP-200, you need to choose which of the 16
channels you wish to transmit data on.
Hold down the TRANSPOSE/FUNCTION button, and press the note in the range
C2–D#3 corresponding to the desired MIDI channel.
Note: When the power is turned on, channel 1 will automatically be selected.
Note: By default, channel 10 will automatically be assigned to the metronome
sound (notes D#5-E5).
Parameter Setting
Transmission channel 1
Reception channel(s) All 16 (1-16)
Local ON
Omni ON
Key Channel Key Channel
C2 1 C#2 2
D2 3 D#2 4
E2 5 F2 6
F#2 7 G2 8
G#2 9 A2 10
A#2 11 B2 12
C3 13 C#3 14
D3 15 D#3 16
