19
4. Appendices
Pitch shifter
This effect modifies the pitch.
PITCH SHIFTER “PITCH”
This pitch shifter can be adjusted over a +/- 2 octave range.
Knob 1 TIME Adjusts delay time.
Knob 2
FEEDBACK
Adjusts amount of feedback
(delay repeats).
Knob 3 PITCH Adjusts amount of pitch change.
Knob 4 FINE Fine adjustment for the amount of pitch
change.
Knob 5 MIX Adjusts the mix amount of effect sound.
Auto wah
This is an auto-wah filter that automatically opens and closes
according to the attack with which you play your guitar. The
effect will vary depending on the guitars volume setting.
FILTRON “FILTRON”
This is a low-pass filter type auto-wah.
Knob 1 TIME Adjusts the speed at which the wah will
rise in response to your picking.
Knob 2
FEEDBACK
Adjusts the peak of the wah sound.
Knob 3 ——— ————
Knob 4 DEPTH Adjusts the sensitivity with which the wah
will respond to your picking.
Knob 5 POLARITY Specifies the direction in which the wah
will operate.
AUTO WAH “AUTOWAH”
This is a band-pass filter type auto-wah that is equivalent to a
pedal wah. It is placed before the DRIVE-AMP effect block.
Knob 1 TIME Adjusts the speed at which the wah will
rise in response to your picking.
Knob 2 ——— ————
Knob 3 ——— ————
Knob 4 DEPTH Adjusts the sensitivity with which the wah
will respond to your picking.
Knob 5
POLARITY
Specifies the direction in which the wah
will operate.
Octave
This generates a pitch one octave lower than the original sound,
and mixes it with the original sound to add a sense of depth and
low end.
This effect may not operate correctly if two or more
strings are played simultaneously, or when low-pitched
strings are played.
OCTAVE “OCTAVE”
Knob 4 DEPTH Adjusts the amount of the ultra-low pitch
(one octave below).
Knob 5 MIX Adjusts the amount of the original sound.
