Korg TRITON Le Service Manual

PART CODE PART NAME NOTE
Q
'TY
001186400
PCB ASSY KLM-1864 TRITON LE76 M. 1
001227700
PCB ASSY KLM-2277 LE61 TRITON LE76 M. 1
001227800
PCB ASSY KLM-2278/9/80/1 LE61 TRITON LE76 M. 1
001233000
PCB ASSY KLM-2330 LE61 TRITON LE76 M. 1
304020230
TR 2SC3661-TA/TB
(
3K
)
(
TS
)
KLM-2277 TRITO 10
304020400
TR 2SA1576A T106
(
TS
)
KLM-2277 TRITO 1
304050220
DIGITAL TR DTC114ESA TP
(
TR
)
KLM-2278/79/80 8
304050270
DIGITAL TR DTB113ZSTP
(
TR
)
KLM-2278/79/80 8
304060250
FET CPH6302-TL
(
TS
)
KLM-2277 TRITO 1
312053100
LED NSPW510BS KLM-2278/79/80 1
313005800
LCD MODULE NCM6602B TRITON LE76 M. 1
314001400
DIODE RLS-73 TE-11
(
TS
)
KLM-2277 TRITO 1
314010300
DIODE 1S2076TD
(
TA
)
KLM-2278/79/80 8
314028800
LED SLZ-190B-09-T2
(
TR
)
KLM-2278/79/80 4
314030500
SCHOTTKY DIODE RB160L-40TE25 KLM-2277 TRITO 1
314030600
DIODE 1SR154-400TE25
(
TS
)
KLM-2277 TRITO 1
314030700
SCHOTTKY DIODE RB051L-40TE25 KLM-2277 TRITO 1
314031000
LED SLR-325VRT31
(
TR
)
KLM-2278/79/80 20
314032000
LED SPR-325MVWT31
(
TR
)
KLM-2278/79/80 1
314032100
ZENER DIODE RD6.8ES T1 AB1
(
TA KLM-2278/79/80 1
315000500
DOUBLE DIODE MC-2840-T12-1
(
TS
)
KLM-2277 TRITO 5
320003217
IC TMP87C847U-4458
(
S
)
KLM-2330 TRITO 1
320004108
IC HD74HC138P KLM-2278/79/80 2
320004681
IC HD6437043AA21F
(
S
)
KLM-2277 TRITO 1
320012223
IC MB87F1710PFV-G-BND
(
S
)
KLM-2277 TRITO 1
320012298
MBM29F160BE-70FTN-K
(
X-0180L
)
:S KLM-2277 TRITO 1
320012299
MBM29F160BE-70FTN-K
(
X-0180H
)
:S KLM-2277 TRITO 1
320040038
IC MX23C6410MC-10 BK4-H
(
S
)
KLM-2277 TRITO 1
320040039
IC MX23C6410MC-10 BK4-L
(
S
)
KLM-2277 TRITO 1
320040040
IC MX23C6410MC-10 BK5-H
(
S
)
KLM-2277 TRITO 1
320040041
IC MX23C6410MC-10 BK5-L
(
S
)
KLM-2277 TRITO 1
324001015
IC UPC4570G2-E2
(
TS
)
KLM-2277 TRITO 4
324001167
IC UPC78L05T-E2
(
TS
)
KLM-2277 TRITO 1
324003010
IC TC7WU04F TE12L
(
TS
)
KLM-2277 TRITO 1
324003022
IC TC7S04FU
(
TE85L
)
(
TS
)
KLM-2277 TRITO 1
324003042
IC TC7W04F
(
TE12L
)
(
TS
)
KLM-2277 TRITO 1
324007011
IC BA09FP-E2
(
TS
)
KLM-2277 TRITO 1
324007012
IC BA033LBSG-TR
(
TS
)
KLM-2277 TRITO 1
324009019
IC NJM2115M-TE2
(
TS
)
KLM-1864 TRITO 1
324011004
IC M5216FP-600C
(
TS
)
KLM-2277 TRITO 1
324017014
IC RN5VD45AA-TR
(
TS
)
KLM-2277 TRITO 1
324021013
IC SN74LV74ANS-EL
(
TS
)
KLM-2277 TRITO 1
324021015
IC SN74LV08ANS-EL
(
TS
)
KLM-2277 TRITO 1
324021025
IC SN74AHCT240PWR
(
TS
)
KLM-2277 TRITO 1
324021030
IC SN74LV04ANSR
(
TS
)
KLM-2277 TRITO 1
324021102
IC SN74LV08APWR
(
TS
)
KLM-2277 TRITO 3
324021103
IC SN74LV32APWR
(
TS
)
KLM-2277 TRITO 2
324021104
IC SN74LV74APWR
(
TS
)
KLM-2277 TRITO 1
324021105
IC SN74LV245APWR
(
TS
)
KLM-2277 TRITO 1
324021106
IC SN74LV139APWR
(
TS
)
KLM-2277 TRITO 2
324021108
IC SN74LV138APWR
(
TS
)
KLM-2277 TRITO 1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
