1. Heating element
2. Shelf position
3. Indicator light
4. Heating position
5. Timer knob
6. Cord and plug
7. Glass door
8. Door handle
9. Baking net
10. Tray handle
11. Food tray
12. Rotisserie Handle
13. Rotisserie fork
PARTS IDENTIFICATION
CIRCUIT
SPECIFICATION
Model No. KOT 1921
Power Supply 230V AC, 50Hz
Power Consumption 1380W
Package Dimension 470 x 355 x 360 mm
Net Weight 5.5 Kgs
4
