KOS Quadrat - Page 11

11
Attenzione:
Coibentare le pareti
Attention:
Insulate the walls
1200 mm
(47,24”)
1180 mm
(46,45” )
20 mm
(7,87” )
section
A : A
= =
2110 mm
(83,07”)
= =
2000 mm
(78,7”)
A A
2250 mm
(88,58”)
1000 mm
(39,37” )
OK
ATTENTION
500 mm
(19,68”)
ATTENTION:
500 mm
(19,68”)
680 mm
(26,7”)
IT - Predisposizione muratura
GB - Preliminary masonry
DE - Vorbereitung Mauerwerk
FR - Prédisposition de la maçonnerie
ES - Disposición de pared
PT - Predisposição alvenaria
Quadrat
built-in
IT Coibentare le pareti
GB Insulate the walls
DE Isolieren Sie die Wände
FR Isoler les murs
ES Aísle las paredes
PT Isolar as paredes
