KOS Quadrat - Page 8

8
A A
2110 mm (83”)
395 mm
(15,5”)
267 mm
(10,5”)
1560 mm (61,4”)
1020 mm (40,15”)
680 mm (26,7”)
30 mm (1,18”)
550 mm
(21,6”)
295 mm
(11,6”)
2110 mm (83”)
1750 mm (68,9”)
1020 mm (40,15”)
1560 mm (61,4”)
A-A
IT - TOLLERANZA
GB - TOLERANCE
DE - TOLERANZ
FR - TOLÉRANCE
ES - TOLERANCIA
PT - TOLERÂNCIA
±0,5%
IT - Misure di ingombro
GB - Footprint dimensions
DE - Platzbedarf
FR - Mesures d’encombrement
ES - Medidas totales
PT - Medidas totais
Quadrat
Free StandingBuilt-in
