7
GB-045BC_f.854
language version). To change the parameters value push (position ickering) and turn
the knob. Push the knob to conrm a changes.
Notice: conrm a new parameter value within 10 seconds, otherwise you will lose it.
The new parameter value will be saved when you exit menu using [>EXIT].
You can switch between the following parameters:
• [>SET TEMP] temperature (min-max) - °C,
• [>T INLET] inlet temperature value - °C,
• [>T OUTLET] outlet temperature value - °C,
• [>FLOW] ow rate - l/min,
•
[>FULL POW] percentage of maximum power with which the unit currently heats, -%,
• [>T - h] work time,
• [>BRIGH MIN] minimum brightness / stand-by-mode (0 - BRIGH MAX),
• [>BRIGH MAX] maximum brightness / active (BRIGH MIN -25),
• [>ENGLISH] select language version (POLSKI, FRANCAIS, ENGLISH, DEUTCH,
РУССКИИ, CESKY, ESPANOL),
),
• [>TEMP LIMIT] maximum temperature limit (min setting - max setting)
Notice: a new maximum temperature value will be saved in memory for other
temperature settings as well,
If you try to set the temperature above the adjusted maximum value the display will
show
for about 1 second.
• [>HE TEST] for authorized service only,
• [>POWER SET] congured power value,
- push knob to check a software version (PW...,MSP...),
- restore to factory settings [FACTORY SET] or to restart controllers [RESET],
- push and keep knob (for about 5sec., until the display show [--]) to up grate
[FACTORY SET] and [RESET] function,
• [>EXIT] save a new parameters and menu exit.
Notice: parameters view mode will automatically exit (without saving changes) after
5 minutes since the last adjustment.
