Technical references
9
P9-1
Summary of synchronous connector
Connector in service: D-SUB 9-pin type
Engagement: M3
Dedicated synchronous cables
K9L-SC48 (D-SUB

~ D-SUB

) 5m For connecting VK2
K9L-SC48D (K9L-SC48 + BNC Cable N = 2) 5m For connecting VK2D
Caution
If you intend to use external synchronization connector, please contact Kowa
distributer.
Pin No. Signal
1 TIMER START
2 GND
3 GND
4 TRIG–IN(STROBE)
5 GND
6 TRIG–OUT(TRIG)
7NC
8NC
9NC
