(see “Clearance to Combustibles” section for more information).
3. This heater can not be installed in any sleeping room of the mobile home.
4. The heater must be grounded to the steel chassis of the mobile home
(unless this is not required by local code).
WARNING: DO NOT INSTALL IN A BEDROOM OF A MOBILE HOME
III. OPERATION
1. General overview
The first step in understanding your new KOZI heater is to familiarize yourself with its
operation. Your heater has 3 main systems: Feed, Combustion and Circulation. These 3
systems work together to produce enough heat for your room. The feed system uses an
auger to “feed” the pellet fuel into the burn pot. The combustion system provides the air
for the fuel to burn and pushes the “smoke” outside through the vent pipes. The
circulation system takes cold air from the room and pushes it through the heat exchanger
where it will warm up and flow back into the room as hot air. These 3 main systems are
all control by the MX2
TM
control system (see Figure 16). The MX2
TM
control system
will be described in more detail later.
CAUTION: THE STRUCTURAL INTEGRITY OF THE FLOOR, WALL AND
ROOF OF THE MOBILE HOME MUST BE MAINTAINED.
Figure 16. MX2
TM
control
FAN
AUGER
ON/OFF
TRIM
MODE SELECT
INDICATOR
LIGHT
MODE SELECT
(AUTO,
HIGH/LOW,
MANUAL)
HEAT SELECT
INDICATOR
LIGHT
HEAT SELECT
