Kozyard Apollo - Step 5: Connect Solidifying Bars

12’X14’ assembly manual
page 9
Affix the frame with Corner Solidifying Bars (Parts J1, J2) using #1 screws as shown in
diagram.
J2 x4
J1 x4
#1 x32
J2
J
1
#1
#1
#1
X4
Measure (DIAGONALLY) from posts to posts to
assure alignment so all materials fit as planned.
Diagonal 1
Diagonal 1 = Diagonal 2
Diagonal 2
J1
J2
J1
J2
J1
J2
J1
J2
Parts Required:
STEP 5: Connect Solidifying Bars with Beams and Poles
Tip:
