①
②
②
U6
U6
U6
U6
U1
U1
U
1
U
1
X4 X4
page 20
Parts Required:
②
①
#1
#1
U4 x4
U3 x4
Attach Solidifying Bars ( Part U1, U6) to roof bar or corner roof bar using Iron Angle (Part U3, U4) and
screws #1 as shown in diagram.
U3
U4
Attention:
If the holes on Solidifying Bar (part U1,U6) and
the hole of the roof panel cannot be aligned,
please djust or loose screw #1, until the screws
of the roof panel in place.
12’x14’ assembly manual
Step 16:
Connect Solidifying Bars
#1 x24
U6 x4
U1 x4
To Next Page
