Kozyard Apollo - Main Frame Assembly; Step 1: Set Up Poles

12’x14’ assembly manual
page 5
A x4
L x4
#1
x12
#8 x16
R2
R2
Parts Required:
Step 1: Set up Poles
When anchoring into concrete over 3 inches, you may use 3/8" x 3" length sleeve anchors.
A
A
L
X12
3 inches
3/8
inches
M6
(Not included)
Reference for anchoring gazebo: Only anchor after completing assembly.
1. Set up Poles (Part A) with Bracket (Part R2) and Stand Plates (Part L) using
#8 and #1 screws as shown in diagram.
R2
x8
#1
#1
#1
A
L
R2
(Inclined Plane)
R2
#8
#8
#8
#8
Attn: Once assembly has been completed: Please reinforce as shown above if gazebo is installed in a high wind area, are
prone to strong winds during bad weather or when wind scale reaches Level 5 or above.
