Kozyard Caesar - Gazebo Assembly Guide; Frame Construction

Caesar 12’x14’ assembly manual
page 4
A5 x4
L5 x4
1#
x12
Parts Required:
X12
3 inches
3/8
inches
M6
(Not included)
A5
L5
A5
L5
1#
1#
1#
X4
Step 1: Set up Poles
1. Set up Poles (Part A5) with Stand Plates (Part L5) using screws #1 as
shown in the diagram.
Reference for anchoring gazebo:
• If the ground is concrete and its depth is over 3 inches, you can purchase 3/8" diameter x 3" length
sleeve anchors.
• Only anchor after finishing all the assembly.
After assembly, we strongly recommend anchoring the gazebo to your deck or concrete as
shown above. Damage resulting from wind or improper anchoring is not covered under warranty.
