page 5Caesar 12’x14’ assembly manual
X2
E6
E6 D6
E6
D6
D6
F5
F5
F5
1#
1#
1#
1#
X2
F7
F7 G7
F7
G7
G7
F5
1#
1#
1#
1#
1. Connect Beams (Part E6, D6) into one beam using Union Bar (Part F5) with
screws 1# as shown in the diagram.
2. Connect Beams (Part G7, F7) into one beam using Union Bar (Part F5) with
screws 1# as shown in the diagram.
Parts Required：
F5 x4
1#
x40
E6 x2
F7 x2 G7 x2
D6 x2
Step 2: Connect the Beams
Long Beam Overall:
Short Beam Overall:
