07 08
2500V
1000V
View the memory data, when the data is invalid,display---
Source voltage rating for insulation test
READ
DC Voltage function is selected
Insulation test Indicator. when the rotary switch at insulation position, this sign appers, when the test voltage
is present, the sign alternate on or off
DC
AC Voltage function is selected
AC
In insulation test mode, test voltage unit
VDC
Minus, When the measure value lower than 0, display the sign.
Greater symbols, In insulation test mode, indicates the measure value overflow.
Unsafe voltage warning, In insulation mode, indicates greater 20V voltage is detected on the input terminals.
Continuity test function is selected
Auto power off function is selected
TEST
Timer unit
Measure unit
Display the Max, Min Avg value
Ω
Appears on primary display indicates the battery too low for reliable operation, please replace battery.
batt
Appears on Auxiliary display, Indicates the battery too low to perform Insulation test
bat
Preset value
PrES
Auto power off function is disabled
POFF
In insulation mode, indicates meter have detected the voltage on the input terminals
In insulation mode, indicates the meter performs the auto discharge function; not to touch any input terminals in this
mode.
Store measuring data
Delete the selected data
Delete all memorized data
The limited value is invalid
Measure unit
LIVE
DISC
SAVE
dEL n:
dEL ALL
----COMP
The lower limited value
The upper limited value
COMP Hi
COMP Lo
