KPS-PF10 • Leakage clamp meter
ENG
1. SAFETY INFORMATION
The clamp leaker series has been designed according to EN61010 -1 and
EN61010 - 2 - 032 concerning safety requirements for electrical measuring
instruments and current clamps with double insulation overvoltage category
600V CAT III and pollution 2.
2. SYMBOL EXPLANATION
Important safety information, refer to the operating manual.
Double insulation ( Protection Class 600V CAT III).
CATIII
Measurement category III, it is for measurements performed
on circuits directly connected to the low voltage installation.
3. DESCRIPTION
Refer to the gure and to the following steps to familiarize you with the clamp
leaker.
1. Transformer jaws
Pick up the AC current owing through the conductor.
2. Hold button
When this button is pushed, the display will keep the last reading and “ ” symbol
will appear on the LCD until pushing it again.
3. Slip Key (select range)
The key is used to select measuring range.
4. Slip Key (Power ON or OFF)
The key is used to turn the meter on or off
5. Display
3 1/2 digit, 7 segment, 13mm high, LCD.
6. Trigger
Press the lever to open the transformer jaws. When the lever is released, the
jaws will close again.
To Next Page
