Kramer 101L User Manual

6
101L - Technical Specifications
5 Technical Specifications
INPUT:
1 composite video, 1Vpp/75 on a BNC connector
OUTPUT:
1 composite video, 1Vpp/75 on a BNC connector
MAX. OUTPUT LEVEL:
2.5Vpp
BANDWIDTH:
500MHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03Deg.
S/N RATIO:
75dB
CONTROLS:
Level: -0.8dB to 6.5dB; equalization: 0dB to 8dB @ 5MHz
COUPLING:
DC
POWER CONSUMPTION:
12V DC, 60mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
5.32cm x 4.36cm x 7.25cm (2.09" x 1.72" x 2.85") W, D, H
WEIGHT:
0.15kg (0.55lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
RK-1 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
