SL-12 - Technical Specifications
13
6 Technical Specifications
BIDIRECTIONAL PORTS:
1 RS-485 and 4 RS-232 serial on 3-pin terminal blocks, 4
GPI/O on 2-pin terminal blocks, 1 K-NET on 4-pin
terminal block connector, 1 Ethernet on an RJ-45
connector, 1 Mini USB connector for local programming
services, 1 built-in IR sensor and 2 IR-in on 3.5mm mini-
jack (for learning).
INPUTS:
1 built-in IR sensor
2 IR-in on 3.5mm mini-jack (for learning)
OUTPUTS:
4 IR-out and 8 relays (36V AC or DC, 2A, 60VAC
maximum on non-inductive load) on 2-pin terminal block
connectors.
INDICATORS:
LED indicator for each port and function.
POWER CONSUMPTION:
12V DC, 550mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
14.3cm x 12.2cm x 4.4cm (5.6" x 4.8" x 1.7") W, D, H
WEIGHT:
0.6kg (1.4lbs)
SHIPPING DIMENSIONS:
31.9cm x 16.5cm x 6.7cm (12.6" x 6.5" x 2.6") W, D, H
SHIPPING WEIGHT:
1kg (2.2lbs)
ACCESSORIES:
Power supply
OPTIONS:
RK-13 19” rack mount, RC-4 remote controller, IR emitter
cables (P/N: C-A35/IRE-10; two IR Emitter Extension
Cables are also available: a 15 meter cable and a 20
meter cable), IR sensor cable (P/N: 95-0104050)
