Kramer VM-2UHD - Technical Specifications

VM-2UHD – Technical Specifications
11
6 Technical Specifications
INPUT:
1 HDMI connector
OUTPUTS:
2 HDMI connectors
PORT:
1 USB for firmware upgrade
MAX. DATA RATE:
10.2Gbps (3.4Gbps per graphic channel)
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
CONTROLS:
EDID Setup button
INDICATOR LEDs:
IN, OUT 1 to 2 LEDs
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
5V DC, 1A
DIMENSIONS:
12cm x 7.15cm x 2.4cm (4.73" x 2.82" x 0.95") W, D, H
WEIGHT:
0.17kg (0.37lb)
SHIPPING DIMENSIONS:
23.2cm x 12cm x 8.9cm (9.41" x 4.73" x 3.51") W, D, H
SHIPPING WEIGHT:
0.67kg (0.67lb)
INCLUDED ACCESSORIES:
Power supply
Specifications are subject to change without notice
For the most updated resolution list, go to our Web site at http://www.kramerelectronics.com
