7 Technical Specifications
Table 5 includes the technical specifications:
Table 5: Technical Specifications
1
of the VP-108 1:8 XGA / Balanced Stereo Audio DA
INPUT:
1 XGA on an 15-pin HD connector; 1 balanced audio +4dBm 100k on
detachable terminal block connectors
1 LOOP on an 15-pin HD connector
OUTPUTS:
8 XGA on 15-pin HD connectors; 8 balanced audio +4dBm 100k on
detachable terminal block connectors
MAX. OUTPUT LEVEL: VIDEO: 1.5Vpp AUDIO: 25Vpp
BANDWIDTH (-3dB): VIDEO: 400MHz AUDIO: >100kHz
DIFF. GAIN: 0.03%
DIFF. PHASE: 0.03 Deg.
K-FACTOR: <0.05%
S/N RATIO: VIDEO: 74.3dB AUDIO: 93dB unweighted
CONTROLS: VIDEO: Level : -1.1dB to +6.2dB;
Equalization: 0dB to +8dB, 50MHz
AUDIO: Level : -0.9dB to +8.6dB
COUPLING: VIDEO: DC AUDIO: DC
AUDIO THD + NOISE: 0.005%
AUDIO 2nd HARMONIC: 0.003%
POWER SOURCE: 90-260 V AC, 50/60Hz, 25VA
DIMENSIONS: 19-inch (W), 7-inch (D), 1U (H) rack mountable
WEIGHT: 2.6kg (5.7lbs) approx.
ACCESSORIES: Power cord, Null modem adapter, Windows®-based Kramer control software
