4
Lance with trigger gun
The machine can only be operated when the safety trigger is squeezed. The
machine can only be operated when the safety trigger is squeezed. When
the lever is squeezed, the spray gun opens. The liquid is then pumped to the
nozzle. The spray pressure increases and quickly reaches the selected opera-
ting pressure.
When the trigger is released, the trigger gun closes and any further spraying of
liquid from the lance is stopped.
The increase in pressure when the trigger gun is closed causes the unloader
valve-safety valve to open. The pump remains switched on and continues
to pump liquid through the pump at reduced pressure. When the trigger gun
is opened, the unloader valve - safety valve closes and the pump ressumes
pressure spraying from the lance.
The trigger gun is a safety device. Repairs should
only be performed by qualified persons. Should re-
placement parts be required, use only components
authorized by the manufacturer.
Unloader valve - safety valve
The unloader valve - safety valve protects the machine from a build p of ex-
cess pressure, and is designed not to permit an excess pressure to be selec-
ted for operation. The limit nut on the handle is sealed with a spray coating.
*(see page 22:“Stopping leaks from the hose or gun“.)
The operating pressure and spray rate can be steplessly adjusted by turning
the handle.
Replacements, repairs, new adjustments and sealing
should only be performed by qualified persons.
Description
