15
8.
Steering the machine: To change
direction tilt machine by pressing a foot
against the footrest and pull the handle
at the same time. Then turn machine
into desired direction.
9.
Connect machine to water mains
(2 - 8 bar pre-pressure).
Inside diameter of hose minimum
1/2 ". The water storage tank is filled
with water. The float valve shuts
the water intake as soon as the tank is
full.
10.
Connect to power circuit
. Make sure
that the main switch is on the "OFF"
position.
T
he socket must be protected with a
16A delay action fuse on the mains
side
.
7.
Move machine to job site.
Kränzle-therm appliances are movable
machines with a sturdy chassis.
11.
Release fixation of hose drum.
12.
Unwind HP hose from hose drum
without kinks and nooses
.
Open gun before reeling up or
unreeling the hose in order to bleed
pressure from hose.
