4
Diagram and Parts List
A
B
C
D
E
F
G
H
I
J1
J2
J3
K
L
A. Spray Head
B. Faucet Body
C. Washers
D. Mounting Nut
E. Screws
F. Weight
G. Weight Clip
H. Quick Connector Assembly
I. Sensor Control Box
J. Battery Pack
J1. Battery Pack
J2. Screw
J3. Anchor
K. Battery
L. 2.5mm Hex Wrench
