9
1. From above the countertop, insert the drain body into the 1 3/4” drain opening of your sink.
2. From underneath the countertop, insert the concave white rubber washer onto the drain.
3. Pushing the washer all the way up until it is in contact with the countertop.
4. Insert the firm washer onto the drain body until it comes into contact with the concave white
rubber washer.
5. Screw the brass nut onto the drain body until it touches the firm washer.
Pop Up Drain Top
Thin Soft Rubber Washer
Concave Washer
Firm Washer
Nut
DO NOT OVER TIGHTEN THE DRAIN!!!
Tail Pipe
To Next Page
