8
Pop Up Drain & Mounting Ring Installation (Only if Included)
Locate and disassemble your pop up drain in the following order:
· Unscrew the tail piece
· Unscrew the brass nut
· Remove the firm washer
· Remove the concave washer, leaving the top thin rubber washer on.
Pop Up Drain
Mounting Ring
White Rubber Washer
Top View
Inner Black Rubber Washer
Bottom View
