Step 3: Securing the faucet assembly
Install the weight clip (H) at the point of
the hose marking "weight here". Insert
the weight (G) onto the weight clip (H)
by sliding it down onto the weight clip (H).
Step 4: Connect waterlines to main valve
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)
6
Weight
here
Weight
he
re
H
G
Connect the filter water inlet pipe (b) into the
end of the filtration manifold (not including).
Pull moderately to ensure the connection has
been made.
b
NOTE: 3/8" typical connection attached. 1/4"
connector / reducer included in the box for
A-typical connections.
NOTE
are installed before connecting to
the main valve.
