Kraus KPF-1612 User Manual

11
Water will not shut off
completely
Cartridge (14) may be
defective
Unscrew the lever (9)
on the handle (11) by
hand. Loosen set screw
(10) with a hex wrench
(2.5 mm). Remove
the handle (11) and
unscrew cartridge cover
(12) by hand. Unscrew
the locking nut (13) with
an adjustable wrench.
Remove ceramic disc
cartridge (14). Check for
cracks
Leaking between spray
head (1) and the hose
(22)
Spray head (1) may be
loose or washer (23) is
not seated correctly in
the hose connection
Tighten the spray head
(1) by hand until snug.
Make sure the washer
(23) is seated correctly
Trouble - Shooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following corrective steps:
PROBLEM CAUSE ACTION
Leakage under the
handle (11)
Locking nut (13) has
come loose
Unscrew the lever (9)
on the handle (11) by
hand. Loosen set screw
(10) with a hex wrench
(2.5 mm). Remove
the handle (11) and
unscrew cartridge cover
(12) by hand. Tighten
locking nut (13) with an
adjustable wrench
