Kreg Jig K5 User Guide

www.kregtool.com 800-447-8638
Introduction
Parts
Owning a Kreg Jig
®
opens up new project possibilities. This Guide shows
you how to adjust your jig and drill pocket holes. You may fi nd the following
resources helpful:
Kreg Online: To view videos of the Kreg Jig
®
K5 in use, order more pocket-
hole screws, or view accessories available for your jig, go to kregtool.com.
Kreg Owner’s Community: Sign up as a member, create your own page, view
other members’ projects, post photos of your projects, view how-to videos, and
participate in forums by going to kregjig.ning.com.
Kreg YouTube Channel: For project, product, and how-to videos, visit
youtube.com/user/kregtoolcompany.
Kreg on Facebook: Connect with Kreg on Facebook to share your projects and
to get inspiration from our fans and friends at facebook.com/kregJig.
Your Kreg Jig
®
K5 is almost ready to use right out of the box. Apply the screw-
length selection guide label to the inside of one extension lid. Place the jig on
your workbench and fi t the dovetail keys on the extensions into the dovetail
slots in the base. The jig and extensions feature holes for mounting to a board.
A
G
E
F
J
B
I
C
D
H
K
L
M
S
Q
R
V
N
U
P
T
W
O
S
For a complete listing of repair parts, see the
Kreg Jig
®
K5 manual at www.kregtool.com.
Assembly

Kreg Jig K5 Specifications

General

Product Name	Kreg Jig K5
Category	Power Tool
Type	Pocket Hole Jig
Material Support	Yes
Dust Collection	Yes
Storage	Yes, with storage wings
Material	Nylon, steel, glass-filled nylon
Thickness Settings	1/2" to 1-1/2"
Drill Guide Compatibility	Kreg drill bits
Included Components	drill bit
Clamping Method	Over-center toggle clamp
Clamp Type	Over-center toggle clamp
