Parts
Base:
Features four holes for securing the jig to a work bench or auxiliary base.
A
Drill-guide socket:
Accepts all Kreg drill guides: Micro, Standard (included), and HD
B
Toggle handle:
Operates workpiece clamping mechanism.
C
Clamp assembly:
Powerful internal spring applies clamping pressure.
D
Ratchet plate:
Provides clamp-assembly adjustment.
E
Ratchet release:
Disengages clamp assembly from ratchet plate.
F
Standard drill guide:
Features marks for positioning the guide for different workpiece thicknesses.
G
Locking pin:
Spring-loaded pin locks the drill guide into the drill-guide socket at the selected setting.
H
Step bit:
Simultaneously drills a pilot hole and clearance hole, forming a bearing shoulder for the screw head.
I
Stop collar:
Controls drilling depth.
J
Hex wrench
For the stop-collar set screw.
K
Stop-collar setting block
Ensures proper positioning of the depth collar on the drill bit.
L
Driver bit:
#2 square-drive bit 6" long.
M
Workpiece stop:
Stop snaps into keyhole slots in the base.
N
Workpiece stop fi ne-adjustment nut:
¼-20 nut fi ts into hex recess in workpiece stop.
O
Knurled nut:
Nylon knurled nut acts as jam nut to fi x the position of the fi ne-adjustment screw.
P
Fine-adjustment screw:
¼-20 x 2 ½" Nylon bolt threads into nut to provide no-slip fi ne adjustment.
Q
Vacuum port:
Accepts a 1¼" shop vacuum hose for effi cient chip removal, swivels side to side.
R
Extensions:
Provide support for wide workpieces and storage for bits and accessories.
S
Screw-length selection guide:
Apply this self-adhesive label to the inside of an extension lid for easy reference.
T
Spacer block:
In repair applications, positions the drill guide for drilling pocket holes in ¾"-thick material
U
Pocket-screw sample pack:
Contains 10 each of the fi ve most often used screws.
V
Pocket-hole plug sample pack
Contains fi ve paint-grade wood plugs.
