PSE 75 EDITION English
7
Application
The Pneumatic Drill Hammer can be used universally
for impact drilling, for light chiselling work in masonry
and for drilling as well as screwdriving in wood, metal
and plastic.
Before putting the machine into operation, read
through these operating instructions completely and
observe the safety instructions contained therein as
well as those in the enclosed booklet on general
safety instructions for electro-tools.
If the mains cable is damaged while working, pull
the mains plug immediately.
Never work with a damaged mains cable.
Wear protective glasses, hearing protection, pro-
tective gloves and sturdy shoes.
For safety reasons, work only with the auxiliary
handle
12
mounted.
Do not work with materials containing asbestos.
Do not carry the machine by the cable.
The mains receptacles in the working area must be
protected by a residual current circuit breaker (RC).
For the attachment of identification markings on the
machine, do not drill into the housing. The protec-
tive insulation would be shorted. Use stickers.
When the drill unexpectedly jams, the machine
kicks back. Therefore, always take a secure stance
and hold the machine firmly with both hands.
1
Tool holder
2
Dust protection cap
3
Unlocking collar
4
Rotation stop switch
5
Locking button for on/off switch
6
On/Off switch/Speed control
7
Ventilation slots
8
Latch for mains cable module
9
Rotational direction switch
10
Drilling/Impact drilling selector
11
Holder for depth stop
12
Auxiliary handle
13
Adapter for screwdriver bits/drill chuck
Accessories illustrated or described are not always
included as standard delivery items.
Measured values determined according to
EN 50 144.
Sound pressure level: 83,5 dB (A)
Sound power level: 96,5 dB (A)
Workplace related emission value: 86,5 dB (A).
For operation, noise protection measures are
required.
The weighted acceleration is typically 8,6 m/s
2
.
1
Safety Instructions and
Accident Prevention
2 Illustration
3 Technical Data
Pneumatic Drill Hammer PSE 75 EDITION
Article number 0428 2625
Input power 600 W
Output power 300 W
Electronic speed control
•
No-load speed 0-1050 RPM
Speed under load 0-800 RPM
Load impact rate
while hammer drilling
max.
4274 RPM
Impact energy 2.3 J
Right/Left rotation
•
Clamping collar dia. 43 mm
Euro standard
Tool holder SDS-Plus
Drill dia., max.
Steel 13 mm
Light metal 15 mm
Wood 30 mm
Hammer drilling in conctrete 24 mm
Recommended hammer drilling
range 4-16 mm
Screw dia., max.
Wood 8 mm
Sheet metal 6.3 mm
Weight 2.75 kg
Protection class
II/
4 Noise/vibration information
