Kroeplin F210 - 1. Service elements

15
Contents:
No. Subject Page
1 Service elements 15
2 Display and operating keys 16
3 Functions and programs 18
4 Handling of functions and programs 20
5 General advice on measuring 23
6 Problem report 23
7 Power supply 24
8 Accessories – Interface 24
9 Technical Details 25
10 Warranty 27
Gauge types
F102 /
F205 / F210 / F220
F415 / F615
F230 / F240 / F250 / F260 / F270
F435 / F455 / F475 / F495 / F640
Description
1 LCD display
2 Operating keys
3 Movable measuring arm
4 Fixed measuring arm
5 Battery cover
6 Operating lever
7 Measuring contacts
1. Service elements
Description
1 Numerical Display
2 Display inscription
3 Analog display
4 Functions
5 Pointer
6 Scale interval
7 Measuring range
8 Tolerance direction
9 +/- display for comparison measurement
10 MODE key
11 SET key
12 DATA key
13 ON / 0-PRESET key
14 LED red (tolerance limit)
15 LED green (tolerance limit)
