7. Power Supply
Battery type: 1,5V Mignon AA, HR6
Changing the battery:
Observe polarity
Please do not replace the short screws into long screw when tighten the battery cover, as the circuit board will
be damaged.
Tool: Screwdriver for recessed head screws PH 1
Proceeding:
1. Loosen screws from battery cover
2. Remove battery cover
3. Replace battery
( !!! observe polarity !!! )
4. Lock battery cover carefully and look
after the cleanness and position of the
rubber seal!
8. Accessories - Interface
1960-90 Interface Mitutoyo-Digimatic
1960-91 Interface USB
8003-08 Holding unit
0230-38
M2,5 x 6
0230-37
M2,5 x 12
1,5V MIGNON AA
