Introduction
10
Pos: 19 /BA/Einl eitung/Technisch e Daten/Sch wader/Swadro 46 T/42T/38T U S @ 8\mod_1 21931866431 6_78.doc @ 1 16374
Road travel is only permitted with the swivelled rotary arms in transport position.
Type Swadro
38 T
Swadro
42 T
Swadro
46 T
Trailer drawbar standard
Tandem axle standard
Number of rotors Unit 1
Number of arms per rotor Unit 10 13 13
Number of double tines per arm Unit 4
Working width approx. mm 3800 4200 4600
Rotor diameter approx. mm 2960 3300 3600
Height in transport position [H] approx. mm 1750 1750 2700
Height in working position approx. mm 1250 1250 1200
Length [L] approx. mm 4800 4950 5100
Transport width [B] approx. mm 3050 3350 2580
Width in working position approx. mm 3800 4200 4600
Power consumption approx.
kW/HP
19/25 22/31
PTO speed rpm max. 540
Recommended drive speed in use max. rpm 350 - 450
Equivalent continuous sound pressure level less than 70 d B(A)
Acreage approx./h 3.5 - 4 4.5 – 5 5.5 - 6
Tyres 18/8.50- 8.6PR
Lighting voltage 12 volt, 7-pin plug
Max. operating pressure of the hydraulic
system
bar 200
Required hydraulic connections 1x single-action*
Service weight kg 730 790 820
*) EW= Single-action control unit
