Swadro 46T
Pos: 95 /BA/B edienung /Schw ader/Arbeit-Tra nsport_Kreis el Drehsicherung _Schwadtuch _Schutzbügel @ 7\mod_121575 3537625_78.d oc @ 105336
SW46T011
A
7
6
5
Figure 20:
• Turn the rotors until the rotation lock (A) lines up with the tine arm of the rotor shown
here.
• Push in the swath cloth (7).
• Swivel up hoop guards (5) and (6).
