8
Fan Powered Terminal Units IOM
ANALOG ELECTRONIC CONTROLS
Pressure independent control packages are available with
or without hot water or electric heat, automatic or remote
night shutdown, and automatic night setback. All control
arrangements include a standard inlet airow sensor, control
enclosure, SCR fan speed controller, 24-volt transformer, fan
relay, and wall thermostat to match the control type. See
Tables 2A and 2B.
DIRECT DIGITAL CONTROLS (By Others)
Control sequences are available for factory installation
of numerous eld-supplied controls from various
manufacturers including: Andover, Automated Logic,
Invensys (Siebe), Siemens (Landis), Johnson, and others. All
packages include a standard inlet airow sensor, control
enclosure, SCR fan speed controller, 24-volt transformer,
and fan relay. Contact Krueger for information on mounting
eld-supplied controls.
PNEUMATIC CONTROLS
Pressure independent control packages are available with
or without hot water or electric heat, night shutdown and/
or unoccupied heating. All control arrangements include a
standard inlet airow sensor and SCR fan speed controller.
See Tables 3A and 3B.
Single function controller: Provides single function, i.e., DA-
NO.
Multi-function controller: Capable of providing DA-NO, DA-
NC, RA-NC or RA-NO functions.
NO CONTROL UNITS
Control sequences are also available to provide a control
box on units supplied with no factory-installed controls.
These arrangements include a standard inlet airow
sensor, control enclosure, SCR fan speed control, 24-volt
transformer, and fan relay. See Table 4.
PACKAGE NO. DESCRIPTION
2200 Cooling Only
2201 Cooling Only With Automatic Night Shutdown
2203 Cooling Only With Automatic Night Shutdown
2204 Cooling With On/O Hot Water Heat
2205 Cooling With On/O Hot Water Heat With Automatic Night Shutdown
2207 Cooling With On/O Hot Water Heat With Automatic Night Shutdown
2208 Cooling With Proportional Hot Water Heat
2209 Cooling With Proportional Hot Water Heat With Automatic Night Shutdown
2211 Cooling With Proportional Hot Water Heat With Automatic Night Shutdown
2212 Cooling With Up To 3 Stages Of Electric Heat
2213 Cooling With Up To 3 Stages Of Electric Heat W/ Automatic Night Shutdown
2215 Cooling With Up To 2 Stages Of Electric Heat W/ Automatic Night Shutdown
2217 Cooling/Heating with Automatic Changeover
2218 Cooling with Solid State LineaHeat Proportional Heat
PACKAGE NO. DESCRIPTION
2300 Cooling With Sequenced Fan
2301 Cooling With Sequenced Fan & Automatic Night Shutdown
2302 Cooling With Sequenced Fan & Automatic Night Setback
2303 Cooling With Sequenced Fan & On/O Hot Water Heat
2304
Cooling With Sequenced Fan & On/O Hot Water Heat & Automatic Night
Shutdown
2305
Cooling With Sequenced Fan & On/O HotWater Heat & Automatic Night
Setback
2306 Cooling With Sequenced Fan & Proportional Hot Water Heat
2307
Cooling With Sequenced Fan & Proportional Hot Water Heat & Automatic
Night Shutdown
2308
Cooling With Sequenced Fan & Proportional Hot Water Heat & Automatic
Night Setback
2309 Cooling With Sequenced Fan & Up To 2 Stages Of Electric Heat
2310
Cooling With Sequenced Fan & Up To 2 Stages Of Electric Heat & Automatic
Night Shutdown
2311
Cooling With Sequenced Fan & Up To 2 Stages Of Electric Heat & Automatic
Night Setback
2313 Cooling with Solid State LineaHeat Proportional Heat
2314
Cooling with Solid State LineaHeat Proportional Heat and Automatic Night
Shutdown On Loss Of Primary Air
TABLE 2A – Analog Electronic Control Arrangements –KLPS,
KQFS, QFC
TABLE 2B – Analog Electronic Control Arrangements – KLPP,
KQFP, QFV
