Form #: SIDOM.4 Page | 5 Revised: 03/19
Pneumatic Control Arrangement - All control packages are pressure independent (unless otherwise
noted below) and available with or without hot water heat, dual maximum airflow, heating and cooling
maximum airflow and dual minimum airflow. All control arrangements include a standard K4
LineaCross inlet flow sensor.
1100 (Actuator only): DA-NC Pressure dependent control
1101 (Actuator only): RA-NO Pressure dependent control
1102 (Single function controller): DA-NO with or without hot water or electric heat
1103 (Single function controller): RA-NC with or without hot water or electric heat
1104 (Multi-function controller): DA-NO with or without hot water or electric heat
1105 (Multi-function controller): DA-NC with or without hot water or electric heat
1106 (Multi-function controller): RA-NO with or without hot water or electric heat
1107 (Multi-function controller): RA-NC with or without hot water or electric heat
1108 (Dual Maximum Control): DA-NO with or without hot water or electric heat
1109 (Heating/Cooling Maximum Control): DA-NO with or without hot water or electric heat
1110 (Dual Minimum Control): DA-NO with or without hot water or electric heat
1111 (Dual Minimum Control): RA-NO with or without hot water or electric heat
1112 (Heating/Cooling Maximum Control): RA-DO with or without hot water or electric heat
Pneumatic Control Legend
DA: Direct acting thermostat
RA: Reverse acting thermostat
NO: Normally open damper position
NC: Normally closed damper position
Single function controller: Provides single function, i.e., DA-NO
Multi-function Controller: Capable of providing DA-NO, DA-NC, RA-NC or RA-NO functions
No Control Arrangement
0000: Unit with no control box.
D000: Unit with control enclosure and transformer.
D001: Unit with control enclosure and no transformer. Also used for control enclosure and
electric heat.
DXX0: FMA mount for DDC controls with no heat.
DXX1: FMA mount for DDC controls with electric heat.
