Form #: SIDOM.4 Page | 4 Revised: 03/19
Service Access
Provide service clearance for unit access.
Codes
Install units in compliance with all applicable code requirements.
Warranty
All Krueger furnished items carry a 1-year limited warranty from the date of shipment.
Maintenance
No periodic preventative maintenance is required, unless called for by a specific control sequence.
Control Arrangements
The LMHS single duct and RVE / SVE retrofit units are offered with a wide variety of factory-mounted
controls that regulate the volume of air delivery from the unit and respond to cooling and heating
load requirements of the conditioned space. These devices are available in both pneumatic and
electronic arrangements. Some DDC (Direct Digital Controls) control packages provided by others
are also available for consignment mounting.
The following listings contain the basic function arrangements for each control offering. Circuit
diagrams, operating sequences, and function descriptions are contained in separate Application
Data publications because of the variety of functions available. Refer to the specific control
publication for details.
Direct Digital Electronic Control Arrangement (Field Supplied) - Control packages are field supplied
for factory mounting, unless otherwise noted. All DDC control arrangements include an inlet flow
sensor, 24V transformer (optional), and control enclosure. Contact the factory for details about
mounting field-supplied controls.
Analog Electronic Control Arrangement - Pressure independent control packages are available
without supplemental heat, with on/off hot water or electric heat, proportional hot water heat, or with
cooling/heating automatic changeover control. All analog control arrangements include an inlet flow
sensor, 24V transformer (optional), control enclosure, and wall thermostat with LCD display.
2100: Heating control
2101: Cooling control
2102: Cooling with on/off electric heat control
2103: Cooling with on/off hot water heat control
2104: Cooling/heating automatic changeover control
2105: Cooling with proportional hot water heat control
2110: Cooling with Solid State LineaHeat Proportional heat control
2111: Cooling/Heating with automatic change over with up to 3 stages of electric heat control
2113: Cooling/Heating with automatic change over with Solid State LineaHeat Proportional heat
2115: Upstream static pressure monitoring
2116: Downstream static pressure monitoring
