KSB MEGACHEM User Manual

MEGACHEM
7
3 5 7 10 & above
210 Shaft 1 2 2 30%
230 Impeller 1 2 2 30%
321 Deep groove 2 4 6 100%
ball bearing
330 Bearing bracket - - - 2 off
412 O rings 3 5 6 90%
452 Stuffing box gland 2 2 3 30%
458 Lantern ring 2 2 3 30%
461 Packing 2 2 3 30%
( for set of 5 rings )
525 S.P.sleeve 2 3 3 50%
- Set of gaskets 6 8 9 150%
Quantity of spare parts
No.of Pumps
Description
Part no.
9 Interchangeability of components & recommended stock of spare parts
Table no. 9
P
ump
s
ize
Bearing bracket
Description Volutecasing Discharge cover Cooling cover Support foot Shaft Impeller Deep groove ball bearing Bearing bracket Bearing cover Gasket Gasket Gasket Gasket O'ring @ Oil seal Mechanical seal Stuffing box gland Lantern ring Packing Seal cover Splash ring Shaft protection sleeve Washer Hex. bolt Hex. bolt Vent plug Key Key
Part No.
102 163 165 183 210 230 321 330 360 400.1 400.2 400.3 400.4 412.1/.2 421 433 452 458 461 471 507 524 554 901.01 901.03 913 940.1 940.2
25- 150 11512111411111111111111111111
25- 200 2213121111111111111111111111
32- 125 3111131111111111111111111111
32- 160 4112141111111111111111111111
32- 200A 30 5213151111111111111111111111
40- 160 6112161111111111111111111111
40- 200 7213171111111111111111111111
50- 160 8113181111111111111111111111
50- 200 9213191111111111111111111111
65- 125 101131101111111111111111111111
32- 250 113242112222222222222222222122
40- 250 123242122222222222222222222122
40- 315 138262132222222222222222222122
50- 250 143242142222222222222222222122
50- 315 158272152222222222222222222122
65- 160A 40 164252162222222222222222222122
65- 200 175242172222222222222222222122
65- 250 187262182222222222222222222122
80- 160 194242192222222222222222222122
80- 200 206242202222222222222222222122
80-250 217272212222222222222222222122
100-200 22 6262222222222222222222222122
100-250 23 10 3 10 3 23 3333333333333333333133
125-250 A 50 24 10 3 8 3 24 3333333333333333333133
125-400 25 12 3 11 3 25 3333333333333333333133
8 Spare parts
8.1 Ordering spare parts
When ordering spare parts please indicate the following
information which may be taken from the name plates of the
pumps. If the name plate is missing then check on the
discharge flange for serial number. e.g.
Type : MEGACHEM C 50-200
Serial no. : 995 1234-1235
8.2 Recommended spare parts of 2 years of
continuous operation
Table no. : 8
