lares 4.0 Installation manual
23 R30024.120en
2.6 Add-On 4G/LTE
2.6.1 Installation
4G/LTE add-on module is an easy installation module, directly plugged into the lares 4.0 control panel
motherboard, regardless of the lares 4.0 model, using the connector shown in the following image (as an
alternative to Add-On 3G module).
• NOTE1: please pay attention to the correct insertion direction of the SIM card as illustrated.
IMPORTANT: before inserting the micro SIM inside the GSM module, be sure to DE-ACTIVATE the PIN
code request by using a mobile phone.
• NOTE2: micro SIM not included in the package.
Install 4G/LTE module to enrich lares 4.0 with the following features:
• Remote configuration of the control panel through free Ksenia PRO App for installer or from Ksenia
SecureWeb service
• Remote management of the control panel through free lares 4.0 APP for users
• Sending of messages using the SIA DC09 digital protocol, with channel and receiver supervision
• Notifications via SMS, e-mail, voice messages, Push notifications
• Possibility of video-verification of ONVIF IP cameras connected to the local network
• Contact ID protocol to the Surveillance Centers is guaranteed
1 Antenna 4G/cable.
2 4G/LTE add-on module.
3 Slot SIM Card (micro SIM).
4G/LTE add-on
KSI4104001.300
