Ksenia Lares 4.0 wls 96 User Manual

lares 4.0 Installation manual
9 R30024.120en
1.4 Technical data
1.5 lares 4.0 control panel and its peripherals
The following image offers a general overview of lares 4.0 and all the compatible peripherals that can be connected
via BUS - Wireless and IP.
lares 4.0 wls 96 16 40 40 wls 140 wls 644 wls
Power supply voltage 230 V~ -15/+10% 50 Hz 0.4A 230 V~ -15/+10% 50 Hz 0.8A
Power Supply Battery Charger
(Type A norm EN50131-6)
15V ± 1% 1.7A 15V ± 1% 3.5A
Current consumption (med./
stand-by)
50mA 40mA 40mA 60mA 60mA 60mA
Current consumption (max.) 80mA 70mA 70mA 100mA 100mA 100mA
Maximum current available for
external devices
160 mA grade 2 580 mA grade 2
230 mA grade 3
1500 mA grade 2
600 mA grade 3
Max. output voltage ripple 120 mV
Max. current for battery charging 800 mA
Maximum battery recharge
time to 80%
3 h 10 h 24 h
Deep discharge voltage
protection
10 V
Low battery threshold (restore) <11 V (13 V)
Low voltage threshold 12 V
Voltage below which the power supply output fault is signaled
Allocable batteries 2Ah 7Ah 18Ah
Maximum number of inputs 96 16 40 140 644
Built-in inputs (fixed +
programmable)
4 8 8 8 8
Maximum number of
outputs
18 16 40 140 644
Ethernet connectivity
management
YES
Power supply fault detection YES
Over voltage protection YES (17 V)
Combinations of Digital Key More than 4 billions
Alarm transmission system SP2, DP1, SP4, DP3
Time for generation and
transmission of alarm messages
3 sec.
Time for detection and
presentation failures
10 sec.
Protection class IP 34
Security grade 2 3
Environmental class II
Isolation Class I
Overall dimensions (WxHxD) 297x222x58 mm 255x295x80mm - 325x400x90 mm - 325x440x90 mm
Weight (with battery) 2.3 Kg (4.5 Kg) 4.2 Kg (10 Kg)
Operating range +5 / +40 °C
Humidity (not condensed) 95 %
