Diagnosis tool Function introduction and some cautions
1. Diagnosis tool
Function
Description
25PIN
socket
25PIN extension line， insert into the socket
CF groove
For checking the maintenance procedure .
software upgrade etc in the future (function
expansion)
The power cord
For connecting 1PIN power cord and
connecting the battery to upgrade the
software
2.diagnosis tool buttons
▲▼Up and down: choose the test items
◄► Left and right: choose the test item and form feed
ENTER: enter execution
EXIT: exit Quit
Some Caution
1. Check if the ignition Switch is turned on the engine is working
2. Check if turn on the diagnosis tool
3. Check if the diagnosis cable is connecting to the vehicle well
4. Check if the diagnosis socket is short circuit
5. Check if the software version is used for this vehicle
6. Check if the test system is used for this vehicle
7. Check if the System fault indicator is flashing
