KSR IDS-101 - 7. SMC & BRIXTON Diagnosis; 7.1 SMC & BRIXTON diagnosis appendix

63
<Enter>DO AGAIN,
<Exit> EXIT ACTION.
Select “ 2.IGNITION “ (Same with the above)
Select “ 3.MIL OUTPUT “ (Same with the above)
Select “4.FUEL PUMP “ (Same with the above)
Select “ 5.STEP MOTOR ”
STEP MOTOR SETTING:
CURRENT--------STEP
CTRL TOTAL-------STEP
<UP>:+1 <DOWN>:-1
<RIGHT>:+5 <LEFT>:-5
<Exit> leave..
7. SMC & BRIXTON Diagnosis
7.1 SMC & BRIXTON diagnosis appendix
25 PINextension line
diagnosis tool
