1. INTRODUCTION
This manual covers the Power Scan vehicle diagnostic tool . It provides
technical information on using the interface, connections to it, communications
with it, and other related information.
1.1 Tool specification
Input power : DC +10V to 20V
Environment Operation
Operation Temperature :+10ºC to 50ºC
Storage Temperature :-10ºC to 80ºC
Operating Humidity :20% to 80% (non-condensing)
Non-operating Humidity :10% to 90% (non-condensing)
1.2 Brief introduction of instrument
The main controller need to connect the diagnostic cable to get power
supply .Fig 2-1 is the picture of main controller . It provides the user interface for
user to implement major function on front panel ..
